JVC DLA-X95R User Manual

MainUnitRear
.
F
IKLM
F
J
I
Inputterminals
Inadditiontothevideoinputterminal,therearealso
otherconnectionterminalsfordevicessuchas
controllersandoptionalequipment.are
usedintheillustration.
Pleasesee“MainUnitInputTerminals”p.16for
moredetailsabouttheterminalsand.
J
Lampcover
Whenreplacingthelightsourcelamp,removethis
cover.
K
Operationpanel
Formoredetails,pleaserefertothe“Operation
panel”inthediagrambelow.
L
RemoteSensor(rear)
Pleaseaimtheremotecontrolatthisareawhenusing
it.
*Thereisalsoaremotesensoratthefront.
M
Powerinputterminal
Connectthesuppliedpowercordtothisterminal.
Operationpanel
.
[MENU]: Displays the menu
[BACK]: Returns to the previous menu
[JKH I] keys: Selects an item
[OK]: Confirms a selection
[INPUT]: Switches the input
A [STANDBY/ON]: Turns “on”/“off” the
power
15
GettingStarted
