Installation
LensControl
Focus/Zoom/Shift
Foradjustingthelensaccordingtotheprojectionposition
¨“AdjustingtheLensAccordingtotheProjectionPosition”（p.28）
ImagePattern
Setting Description
On Displaysthelensadjustmentpattern.
Off Displaysexternalsignals,anddoesnotdisplaythelensadjustmentpattern.
Lock
Setting Description
On Locksthelenstopreventanyerroneousoperationontheadjustments.

Operationofthelenscontrolfeatureisdisabledwhen“On”isselected.
Off Doesnotlockthelens.
LensMemorySelect/LensMemorySave/LensMemoryNameEdit
Thefocus,zoom,andshiftsettingscanbesavedorretrieved,soyoucanswitcheasilytoadifferentaspectratio(screen
size)accordingtotheimage.
¨“SavingandRetrievingAdjustmentSettings”（p.29）
LensCenter
Returnsthelenspositiontothecenter.
LensCover







Setting Description
Auto Opens/closesthelenscoveraccordingtothepoweron/offoperation.
Open Leavesthelenscoveropenregardlessofthepoweron/offmode.
PixelAdjust



Foradjustingcolorfringingofthevideoimageinthehorizontalandverticaldirections.
Setting Description
Horiz.Red/Horiz.Blue Settingrange:1(movesred/bluetotheleft)to5(moves
red/bluetotheright)
Vert.Red/Vert.Blue Settingrange:1(movesred/bluedownward)to5(moves
red/blueupward)

Itisnotpossibletomaintaintheconsistencyofallpixelsonthescreen.Duetothe
equipment,therewillalwaysbesomedifferences.Colorfringingalsovaries
dependingonthescreenposition.

Thehorizontalandverticaldirectionsarereversedwhentheimageisflipped
laterallyorvertically.

Toadjust,usestillimageswithdistinctoutlines.
MENU
BACK
>
3
3
3
3
Back
Operate
Select
Exit
Installation
Vert. Blue
Vert. Red
Horiz. Blue
Horiz. Red
Pixel Adjust
55
Adjust/Set
