ConnectingtotheTRIGGERTerminal
.
Trigger Input Terminal (Ø3.5)
Screen
Trigger Cable (Sold Separately)
To [TRIGGER] Terminal
This Unit

Donotuseittosupplypowertootherdevices.

Connectingtotheaudioterminalofanotherdevicemaycausethedevicetomalfunctionorbreakdown.

Usingbeyondtheratedvaluewillcausetheunittomalfunction.

Thetriggerterminaloutputsavoltageof12V.Exerciseadequatecautiontopreventshortcircuit.

Thefactorysettingis“Off”.Tochangethesetting,configurethe“Trigger”iteminthemenu(p.62).
ConnectingthePowerCord(SuppliedAccessory)
A
Connectthepowercordsuppliedtothepowerinputterminalon
themainunit
B
Insertthesuppliedpowerplugintothewalloutlet.
Precautionstopreventfireandelectricshock

Thevoltagecapacityofthisunitislarge.Pleaseconnectitdirectlytothewalloutlet.

Whenyouarenotusingtheequipment,pleaseunplugthepowercordfromtheoutlet.

Connectitusingonlythepowercordsupplied.

Donotuseavoltageotherthantheindicatedpowervoltage.

Donotdamage,breakormodifythepowercord.Donotplaceaheavyobjectonthepowercord,orheatorpullit.
Doingsomaydamagethepowercord.

Donotunplugthepowercordwithwethands.
A
B
Power Cord
(Supplied)
25
Setup
