MainUnitInputTerminals
.
A B C
D
F
E
G
I
H
Enlarged View of Rear Face
A
[HDMI1]inputterminal
B
[HDMI2]inputterminal
ForconnectingtodevicesthatsupportHDMIoutput.
(p.22)
ItisfittedtotheM3lockhole.Thedepthofthescrew
holeis3mm.
C
[LAN]terminal(RJ45)
Theprojectorcanbecontrolledbyconnectingittoa
PCthroughthecomputernetworkforcontrol
commandstobesenttotheprojector.
D
[RS232C]terminal(Dsub9pin
male)
TheprojectorcanbecontrolledbyconnectingaPCto
thisterminal.
*TheLANandRS232Cterminalscannotbeusedatthe
sametime.(p.62)
E
[PC]Inputterminal(Dsub15pin)

ThisisaninputterminalusedforPCsignals(RGB
videosignalsandsyncsignals)only.
ItcanbeconnectedtoaPCmonitoroutputterminal,
etc.
F
[3DSYNCHRO]terminal
Byconnectinga3DSYNCHROEMITTER(sold
separately)tothisterminal,youcanview3Dmovies.
G
Componentvideoinputterminals
(RCAx3)
Forconnectingtodevicesthatsupportcomponent
signaloutput.
ItcanbeusedasaninputterminalforanalogRGB(G
onSync),component(Y,Cb,Cr),orDTVformat(Y,
Pb,Pr)signals.
H
[TRIGGER]terminal(

)
OutputterminalforDC12V,100mApowersupply.It
isusedforsendingoutputsignalstocontrolelevating
screensforwhichtheuseofaSCREENTRIGGERis
supported.
Notethatimproperconnectionmaydamagethe
projector.(Tip=DC+12V,Sleeve=GND)
I
[REMOTE]terminal(stereomini
jack)
Usethisterminalwhenaremotecontrolunitisnot
usable,suchaswhentheprojectorisinstalledina
dedicatedboxorforrearprojection.
Connectanexternalremotesensorunittothe
projectorunit.
Fordetailsontheexternalinfraredsensorand
connectingcable,pleasecontactyourdealer.
16
GettingStarted
