© 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
OVERVIEW
This manual describes setting up the KXP system. Be advised, different options and features are available on
different versions of the software. Verify the version and options for the installed software.
MAIN UNIT
Make sure the installed Main Unit is the proper version (KXP, shown below). KXP is composed of KXP-ITX (game
CPU board), GPU card, KXP-IOB (I/O board), and KXP-IFB (interface board).
To operate properly it must be securely installed in the logic unit and connected to the backplane.
RAM CLEAR
USB DRIVE
GAME CF CARD
UPPER SIDE
SYSTEM
SD
CARD
KXP-IOB
KXP-ITX
KXP-IFB
GPU CARD
KXP MAIN UNIT
SYSTEM START UP (NORMAL)
1. Open the Main Door.
2. Turn on the Power Switch.
3. Close the Main Door. The self-check screen is displayed.
4. When the self-check clears with no errors, the game screen is displayed.
