Krone EasyCut 32 P User Manual

Settings
40
Pos: 18.10 /Übersc hriften/Überschri ften 2/A-E/EEinstel lung der Entlastungsfeder n (2015-10-19 15:05: 29) @ 0\mod_11966666594 47_78.docx @ 10133 @ 2 @ 1
8.2 Adjusting the Compensation Springs
Pos: 18.11 /BA/Einste llungen/Mähwerke/Ea syCut/Bodendruc k/Bodendruck allge meiner Text alle EC @ 0\mod_11966 67271181_78.doc x @ 10190 @ @ 1
The ground pressure for the cutter bar is adjusted to local conditions by means of the
compensation springs. In order to protect the sward the load on the mowing spar must be
relieved so that it does not jump when mowing, yet does not leave any skid marks on the
ground.
Pos: 18.12 /BA/Einste llungen/Mähwerke/Ea syCut/Bodendruc k/Bodendruck einste llen Bild EC 28/32 @ 10\mod_12 21738032880_78.doc x @ 136927 @ @ 1
1
2
EC-145-1
Fig. 22
Pos: 18.13 /BA/Einste llungen/Mähwerke/Ea syCut/Bodendruc k/Bodendruck einste llen Text EC 28/32 28/32CV @ 10\ mod_1221737841223_78. docx @ 136908 @ @ 1
Note
Retaining chain shorter= reduced ground pressure
Retaining chain longer= increased ground pressure
If a telescope upper suspension arm is being used (optional)
The higher the compensation springs (1) are hooked into the perforated bar (2), the lower the
pressure on the ground in the front part of the cutter bar.
If the compensation springs are hooked in too high, the mowing unit will tip towards the
rear.
or:
The lower the compensation springs (1) are hooked into the perforated bar (2), the greater the
pressure on the ground in the front part of the cutter bar.
If the compensation springs are hooked in too low, the mowing unit will have too much
weight on the ground in front.
