TECHNICAL DATA 24
141
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 66 N/mm (377 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 68 N/mm (388 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 69 N/mm (394 lb/in)
Spring length 200 mm (7.87 in)
Gas pressure 10 bar (145 psi)
Static sag 25 mm (0.98 in)
Riding sag 115 mm (4.53 in)
Fitted length 367 mm (14.45 in)
Damper oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 144)
24.9 Chassis tightening torques
Hose clamp, radiator - 2.4 Nm (1.77 lbf ft)
Screw, chain guard on chain slid-
ing guard
EJOT PT
®
K60x20 2 Nm (1.5 lbf ft)
Screw, combination instrument on
combination instrument bracket
EJOT DELTA PT
®
45x12-Z 1 Nm (0.7 lbf ft)
Screw, side cover EJOT PT
®
K60x20 2 Nm (1.5 lbf ft)
Screw, spoiler EJOT PT
®
K60x20AL 2 Nm (1.5 lbf ft)
Screw, on and off switch M3 0.4 Nm (0.3 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Spoke nipple M4.5 6 Nm (4.4 lbf ft)
Clamp, wiring harness on engine M5 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, battery terminal M5 2.5 Nm (1.84 lbf ft)
Screw, cable cover on engine M5 6 Nm (4.4 lbf ft)
Screw, shock absorber adjusting
ring
M5 5 Nm (3.7 lbf ft)
Screws, throttle grip M5 3 Nm (2.2 lbf ft)
Attaching Powerpack HV M6 10 Nm (7.4 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw for spoiler attachment M6 6 Nm (4.4 lbf ft)
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, radiator bracket M6 6 Nm (4.4 lbf ft)
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Nut, rim lock M8 10 Nm (7.4 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
