4. LUBRICATION SYSTEM
4-4
DINK 200i/125
Bolts
Oil
Se
p
arator Cove
r
Pump Driven Gea
r
Bol
t
INSTALLATION
Install the oil pump and oil separator and
tighten the two bolts.
Install the pump drive chain and driven gear,
then set the snap ring securely on the pump
shaft.
Install the oil separator cover properly.
Oil Separato
r
Pump Drive Chain Snap Ring
Arrow Mark
Make sure the pump shaft rotates freely
and arrow on the oil pump is upside.
Ϡ
Fit the tab of the separator cover into the
slit in the separator.
Ϡ
