KYMCO DINK 200i Service Manual

1. GENERAL INFORMATION
1-2
DINK 200i/125
SPECIFICATIONS (DINK 200i)
Overall length 2030 mm (81.2 in)
Overall width 780 mm (31.2 in)
Overall height 1255 mm (50.2 in)
Wheel base 1390 mm (55.6 in)
Engine type
Water cooled 4-stroke,
OHC engine
Displacement 174.5 cc (10.48 cu-in)
Fuel Used 92# nonleaded gasoline
Front wheel 58 kg (127.6 lb)
Rear wheel 82 kg (180.4 lb)
Dry weight
Total 140 (308 lb)
Front wheel 65 kg (143 lb)
Rear wheel 89 kg (195.8 lb)
Curb weight
Total 154 kg (338.8 lb)
Front wheel 120/70-13
Tire
Rear wheel 140/70-12
Ground clearance 140 mm (308 in)
Min. turning radius 2350 mm (94 in)
Starting system
Starting motor
Type Gasoline, 4-stroke
Cylinder arrangement Single cylinder
Combustion chamber
type
Semi-sphere
Valve arrangement O.H.C.
Bore x stroke 62×57.8 mm
(2.48×2.312 in)
Compression ratio 11.2:1
Compression pressure
16 kgf/cm
2
(1600 kPa,
227.2 psi)
Open 12 (BTDC)
Intake
Close 35 (ABDC)
Open 28 (BBDC)
Exhaust
Close 8 (ATDC)
Intake 0.1 mm (0.004 in)Valve
clearance
(cold)
Exhaust 0.1 mm (0.004 in)
Idle speed (rpm) 1660±100rpm
Lubrication
type
Forced pressure &
Wet sump
Oil pump type Inner/outer rotor type
Oil filter type Full-flow filtration
Oil capacity
1.1 L (0.968 lmp qt,
1.166 US qt))
Lubrication System
Oil
exchanging
capacity
0.9 L (0.792 lmp qt,
0.954 US qt)
ENGINE
Cooling Type Liquid cooled
Air cleaner type Paper element, wet
Fuel capacity
11 L (2.31 lmp gal,
2.86 US gal)
Type
Programmed fuel
injection
Fuel System
Carburetion
Throttle bore !28 mm (!1.12 in)
Type ECU
Ignition timing ECU control
Spark plug
NGK
DPR6EA-9
Ignition System
Spark plug gap 0.9 mm (0.036 in)
Electrical Equipment
Battery Capacity 12V10AH
Clutch type Dry multi-disc clutch
Type Non-stage transmission
Transmission
Gear
Operation
Automatic centrifugal
Type
Type Two-stage reduction
1st
2.7~0.8
Power Drive System
Reduction Gear
Reduction
ratio
Final
8.48
Front
1.75 kgf/cm
2
(175 kPa,
24.85 psi)
Tire pressure
Rear
2 kgf/cm
2
(200 kPa,
28.4
psi)
Turning Left 42.5
Moving Device
angle
Right 42.5
Fron
t
Disk brake
Brake system
type
Rear Disk brake
Sus
p
ension
Fron
t
Telescope
type
Rear Double swing
Shock absorbe
r
Front Telescope
Damping
Device
type
Rear
Double swing
Frame type Under bone
