12. COOLING SYSTEM
12-3
DINK 200i/125
SPECIFICATIONS
Radiator cap relief pressure 90 kPa (0.9 kgf/cm
2
, 12.8 psi)
Begins to open 80 - 82°C (176 - 180°F)
Thermostat temperature Full-open 90°C (198°F)
Valve lift 3.5 mm (0.14 in) minimum
Radiator and engine 1 liter (1.1 US qt, 0.88 lmp qt)
Coolant capacity
Reserve tank 0.37 liter (0.4 US qt, 0.33 lmp qt)
Standard coolant concentration 1:1 mixture with soft water
COOLANT GRAVITY
Tem
. • •
Coolant
concentration
0 5 10 15 20 25 30 35 40 45 50
5% 1.009 1.009 1.008 1.008 1.007 1.006 1.005 1.003 1.001 0.009 0.997
10% 1.018 1.107 1.017 1.016 1.015 1.014 0.013 1.011 1.009 1.007 1.005
15% 1.028 1.027 1.026 1.025 1.024 1.022 1.020 1.018 1.016 1.014 1.012
20% 1.036 1.035 1.034 1.033 1.031 1.029 1.027 1.025 1.023 1.021 1.019
25% 1.045 1.044 1.043 1.042 1.040 1.038 1.036 1.034 1.031 1.028 1.025
30% 1.053 1.051 1.051 1.049 1.047 1.045 1.043 1.041 1.038 1.035 1.032
35% 1.063 1.062 1.060 1.058 1.056 1.054 1.052 1.049 1.046 1.043 1.040
40% 1.072 1.070 1.068 1.066 1.064 1.062 1.059 1.056 1.053 1.050 1.047
45% 1.080 1.078 1.076 1.074 1.072 1.069 1.056 1.063 1.062 1.057 1.054
50% 1.086 1.084 1.082 1.080 1.077 1.074 1.071 1.068 1.065 1.062 1.059
55% 1.095 1.093 1.091 1.088 1.085 1.082 1.079 1.076 1.073 1.070 1.067
60% 1.100 1.098 1.095 1.092 1.089 1.086 1.083 1.080 1.077 1.074 1.071
COOLANT MIXTURE (WITH ANTI-RUST AND ANTI-FREEZING EFFECTS)
Freezing Point Mixing Rate KYMCO SIGMA Coolant Concentrate Distilled Water
-9• • 20%
-15• • 30% 425cc 975cc
-25• • 40%
-37• • 50%
-44.5• • 55%
Cautions for Using Coolant:
Use coolant of specified mixing rate. (The mixing rate of 425cc KYMCO SIGMA coolant
concentrate + 975cc distilled water is 30%.)
Do not mix coolant concentrate of different brands.
Do not drink the coolant which is poisonous.
The freezing point of coolant mixture shall be 5• •lower than the freezing point of the riding
area.
