12. COOLING SYSTEM
12-13
DINK 200i/125
Remove the four bolts and the water pump
cover, gasket and 2 dowel pins.
Remove the water pump impeller.
Inspect the mechanical (water) seal and seal
washer for wear or damage.
Impeller (Left Hand Threads)
Mechanical Seal
S
eal Washer (Porcelain)
Water Pump Cove
r
Bolts
The impeller has left hand threads.
• •
The mechanical seal and seal washer
must be replace as a set.
• •
Impelle
r
