10EN
Press the icon
.
The icons of the programmable keys
areshownontheservicesdisplay;the
numbersrelativetoeachkeyappearon
thegroupdisplay.
The  key makes it possible to
program water doses with the SELF-
LEARNING function (see specific
paragraph).
Press one of the
coffee keys (ex.
Group 3).
By pressing one of the coffee keys
(e.g.key1),therelativewaterdose
isshownontheservicesdisplayand
theiconofthekeyinquestionremains
highlightedonthegroupdisplay.
Bypressingthe key,thedispensingstartsand
thefollowingscreenappearsontheservicesdisplay:
Theparametersdisplayedare:
Dv: Volumetric meter incremental counter
tG: dispensing time
TB: instant coffee boiler temperature
RB: % activation coffee boiler resistance
P: service boiler pressure
Liv: service boiler water level; % level signal
Rc: service boiler resistance
Evc: service boiler load solenoid valve
TV: Turbosteam wand steam temperature
5. Programming measures function
Press the icon .
Press the icon. Theseparameterscanbecongured:
SET… - to set the dispensing time;
% - to set the water temperature.
NOTE. - the red borderaroundtheiconindicatesthekeybeingchanged.
- the TESTING phaseforthewaterkeysissimilartothatofthecoffee
keys.
Press the icontoconrmtheinformationentered.
Water dose programming
5
3
2
4
1




2
1
