Everybuttononthemachinecanbeconguredbasedonthetypeandtherelativegrinder/dispenser.Notalltypescan
beusedwiththeBDSsystem.Thepossiblechoicesare:
-Singletype
- Short
- Medium->SINGLEDOSE(Red)
- Long->SPECIALDOSE(White/Blue)
-Doubletype
- Short
- Medium->DOUBLEDOSE(Green)
- Long
-NOTE: POSSIBILITY TO CONNECT
ALSO WITH GRINDER/DISPENSER 2
MEDIUM
LONG
SHORT
GRINDER/DISPENSER1
DOUBLEDOSE
(Green)
SINGLEDOSE
(Red)
SPECIALDOSE
(White/Blue)
Setting recipes and connections with grinder/dispenser
Thelterholder-keyandmachineassociationlogicisthefollowing:
1-A or 2-A=activationoftherstactuator
(lter-holderwithsingledeliveryspout)
1-B o 2-B=activationofthesecondactuator(lter-holderwithdouble
deliveryspout)
1-C or 2-C=activationofthethirdactuatorwithlter-holderwithdedicatedlter
With the number 1therstgrinder/dispenserMM1isidentied
With the number 2 the second grinder/dispenser MM2isidentied
With the letters A-B and C thelter-holdersareidentied
