71 EN
Asw =Switchingpowersupply
Bt = Terminal block
Ct = Voltage changing
F = Pump fuse
Fi = Filter
IG = Main switch
Mo =
Terminal strip
MP = Motor pump
RB... = Coffee Boiler resistance
RC = Service Boiler resistance
Rsc = Cup heater resistance
St = Triac board
TC = ServiceBoilersupplysecuritythermostat
TB... =CoffeeBoilersupplysecuritythermostat
Tl = Contactor
TR = Transformer
BT = Battery
J1 = Keyboards
J2 = Turbosteam
J3 = Services Led,gr.1,gr.2
J4 = Display feed
J7 = Led gr.3
J8 = Ledgr.4
J9 = Flat cable of services display,gr.1
J10= Flatcableofgr.1,gr.2,gr.3,gr.4display
P1 = Volumetricmetergr.1,gr.2
P3 = Pressuresensorgr.3,gr.4
P4 = BoilerNTCgr.3,gr.4
P5 = Pressuresensorgr.1,gr.2
P6 = Levelsensor,servicesboilerNTC
P7 = NTCboilergr.1,gr.2
P8 = Keyboards
P9 = Card feed
P11 = Proportional solenoid valve feed Gp
P12 = Solenoidvalvefeed:G1,G2,Evc,Eac,Eds,Va,Eaf,Ev
P13 = Volumetricmetergr.3,gr.4,G3,G4
P16 = EtsTurbosteamSolenoidvalvefeed,MCTurbosteam compressor feed
TS = Turbosteam sensor
TM1 = Alignment Turbosteam sensor Trimmer
TM2 =DisplaycontrastsettingTrimmer
WIRING DIAGRAM LEGEND
Connector list
