PRELIMINARY OPERATIONS
FormataUSBPenDriveusingtheFAT32format.IfusingWindows,usethepredenedformatting
settings as shown in the image.
Copytheupdateles(CPU ; only for M100: DISPLAY
M100.ppf
tft_fw.ppf
)tothemainlepath
ofaUSBPenDrive.
NOTE:donotturnoffthemachineorremovetheUSBPenDriveuntiltheupdatehas
beencompleted.IfusingaUSBPenDriveoperatingLED,thisisshownbytheLED
ashing.
PRELIMINARY OPERATION: Recognizing of USB support
Withthemachinerunning,inserttheUSBPenDrivecontainingtheupdateles
into the USB port. The icon will appear on the display to indicate that the
storage device has been recognised.
STARTING THE SOFTWARE UPDATE
TurnthemachineoffleavingtheUSBPenDriveinserted.Withthesubsequent
restart,the upgrade of the two microprocessors (master and slave) begins with
thele .
The correct recognition of each le by the machine is signalled by a buzzer
(200msON).
Pen Drive operating LED status: ashing (running).
AttheendoftheslaveCPUupdate,programmingofthemasterCPUbegins. Fortheentiredurationofthisphase,
thebuzzersoundsintermittently(200msON).
Pen Drive operating LED status during the update: ashing (running).
The update of the CPU board lasts few minutes and ends when the buzzer emits prolonged intermittent signals (2sec
ON/10secOFF).
Pen Drive operating LED status when update is completed: on (not running).
Insert
theUSBPenDrive; thecopyingofthe2DISPLAY
updatelesbegins
M100.ppf
tft_fw.ppf
The 3.6 boot the key can be left inserted and it
continuestoautomaticallyupdatethedisplaysaswell.
INSERT USB TO
UPDATE DISPLAY
1
2
3
4
5 6
UPDATE SOFTWARE
12C ADDRESS 6E
PLEASE WAIT
BOOT 3.6
UPDATING 015%
