MasterCraft MAXIMUM 055-6768-8 User Manual

model no. 055-6768-8 | contact us 1-800-689-9928
16
KNOW YOUR SLIDING MITRE SAW
No.
Description
1 Switch handle
2 Lower blade guard
3 Mounting hole
4 Quick cam mitre locking lever
5 Mitre handle
6 MItre detent override
7 Positive mitre detents
8 Base
No.
Description
9 Left stop block
10 Left extension wing
11 Left slide fence
12 Hold-down clamp
13 Slide carriage lock knob
14 Carrying handle
15 Safety lock
9
10
11
12
13
14
15
8
7
6
5
4
3
2
1

MasterCraft MAXIMUM 055-6768-8 Specifications

General

Brand	MasterCraft
Model	MAXIMUM 055-6768-8
Category	Saw
Language	English
