Rinse aid and detergent
41
Additional dosage
At each wash cycle approx. 2.4-3.0 litres of fresh water enter the commercial dishwasher, which must be
mixed with detergent powder.
After 5 wash cycles, fill approx. 35 - 45 g detergent powder into the machine.
5.2.2 Automatic dosing of liquid detergent
The dosing amount is set by the authorised service technician when commissioning the machine ( 12.6).
5.3 Pour in liquid detergent and rinse aid
Caution
When filling make sure that no detergent gets into the rinse aid storage tank, and vice versa.
Opening with white flap: Detergent storage tank
Opening with blue flap: Rinse aid storage tank
Take hold of the lower body panel sides
on the storage tanks and fold them for-
ward
Place funnel (1) in the filler opening.
Place container on the funnel and fill
until the float switch (2) is visible.
Fold lower body panels back
Rinse the funnel in the dishwasher after
use.
5.4 Suction tube with level control
For certain machine versions, your machine is provided with 2 suction tubes. The suction tubes are already
connected to the machine.
Caution
Only use the suction tube with sufficiently stable containers. Narrow and tall containers can
tip if the suction tube is pulled.
Do not place the suction tube for the rinse aid in the container with detergent or vice versa.
Do not pull unnecessarily on the suction hose or main power cable, as this may lead to a
defect.
Figure 1:
Suction tube for detergent
White cap
Figure 2:
Suction tube for rinse aid
Blue cap
Figure 1 Figure 2
