External dispenser pumps
66
18 External dispenser pumps
Instead of the internal dispenser pump, external dispenser pumps can also be used. Follow the instructions
in this chapter.
Danger
Danger to life: Live components!
Have the dispenser pumps installed and commissioned by an authorised service technician.
Caution
Reduced splash water protection!
Do not insert cables or tubes into the machine through self-drilled holes.
Use the ducts at the back of the machine.
18.1 Position of the dosing points (detergent, rinse aid)
PG 8165, PG 8166, PG 8169
1 Detergent dosing nipple
2 Rinse aid dosing nipple
PG 8164
1 Detergent dosing nipple
2 Rinse aid dosing nipple
