Display & Cine Review 6-7
Live capture can be divided into 2 kinds: retrospective and prospective.
z Retrospective saving is to save the specified images before the current moment;
to save the images stored in the cine memory to the system hard disk.
z Prospective saving is to save the specified images later than the current moment;
to save the images to both the cine memory and the system hard disk.
The live capture time can be set.
To perform live capture:
z In scanning mode, press the <Save> key on the control panel (The key has
already been assigned the function as “Save Clip (Prospective) to hard disk” or
“Save Clip (Retrospective) to hard disk”).
Tips:
z In retrospective saving, if any parameter is modified during saving, the changes
will not be saved to the cine. While in prospective saving, any parameter
modification before the saving finished can be saved into the cine.
z Press the save key again or <Freeze> to stop saving.
z When a saving is completed, a thumbnail is showed in the Thumbnail area.
Frozen image storage
In frozen mode, press the <Save> key on the control panel (The key has already
been assigned the function as “Save Clip (Retrospective) to hard disk”).
After the cine is successfully saved, there is a thumbnail displayed on the screen.
The live capture time can be set.
6.7 Cine Memory
6.7.1 Cine Memory Setting
There are 2 ways of cine memory split: auto and split.
Setting path: select "Auto" or "Split" for cine memory in [Setup]Æ [System
Preset]Æ[Image Preset]. Where,
z "Auto" for the cine memory indicates the system splits the cine memory as per
the number of B image windows.
z “Split” indicates the system always splits the cine memory, even if in the single-B
window, the system splits the cine memory into two as well. You can press <B>
key to switch and display the images in either memory, so you can compare
images in Split mode.
The memory capacity is evenly distributed as per splitting number, as shown in the
following table (Taking B images in low density as an example, the capacity of B cine
memory is N frames):
Imaging Mode
Split
Single-B/ Color Dual Quad
Auto One memory, with
capacity N frames.
The memory splits into
two, with capacity N/2
frames each
The memory splits into
four, with capacity N/4
frames each
Split The memory splits into
two, with capacity N/2
frames each
The memory splits into
two, with capacity N/2
frames each
The memory splits into
four, with capacity N/4
frames each
