12-8 Setup
12.2 Exam Preset
Open “[Setup]Æ[Exam Preset]” to enter the following screen.
You can assign available exam modes for probes.
1. To select a probe, move the cursor onto the Probe column, and select the probe
model through the drop-down list.
2. Select/delete exam modes:
On the right side of the screen, you can view the current exam modes supported by
the probe. On the left side, you can view all the available exam modes in the exam
library for the probe.
z Select the exam from the Exam Library on the left and click to add it to
the Exam Selected.
z Click to add the exams, which Exam Library has but Exam Selected
doesn’t have, from Exam Library to Exam Selected.
z To delete an exam supported by the current probe, select the exam first, and
then click
to delete it.
z Click [Delete] to delete the user-defined exam mode.
z Click [Default] to set a selected exam mode as the default exam mode, and the
default exam mode is moved up to the first.
12.3 Measure Preset
For details about Measure Preset, please refer to the [Advanced Volume].
