5.6.2 PW/CW Mode Image Parameters
In PW/CW mode scanning, the image parameter area in the top-right corner of the
screen displays the real-time parameter values as follows:
PW Parameter F G PRF WF SVD SV Angle
Meaning Frequency Gain PRF Wall
Filter
SV
Position
SV Size Angle
CW Parameter F G PRF WF SVD Angle
Meaning Frequency Gain PRF Wall Filter SV Position Angle
îš„ During PW/CW mode imaging, the image optimizing menus for B mode and PW/CW
mode are displayed on the touch screen at the same time. If Color mode (Power
mode) is also working, menus for certain modes will be displayed on the touch
screen synchronously, and you can switch between them by clicking the mode tabs.
îš„ When you adjust the depth of the B mode image, related changes will occur in the
PW/CW mode image as well.
îš„ Most of the parameters are the same for the PW mode and CW modes, so
parameters of both are combined together to be introduced here.
Only phased probes support CW mode.
