Mindray DC-8 EXP User Manual

Small Parts 10-3
Modes Types Tools Descriptions Methods or formulae
Doppler
Measurement
STA
Superior Thyroid
Artery
D trace in General D
measurements
ITA
Inferior Thyroid
Artery
Calculation / / /
Study / / /
10.4 Small Parts Measurement Operations
Tips: 1. See table "10.3 Small Parts Measurement Tools" above for measurement tools
and methods.
2. For the definitions of measurement, calculation and study, refer to "1.3
Measurement, Calculation and Study".
3. The order of the measurement items is presettable, see "2.4.2 Application
Measurement Preset" for details.
4. A measurement tool can be activated by clicking the item either in the
measurement menu or touch screen menu, it is described as "Select/Click ...
(certain item) in the measurement menu" in the following procedures.
10.4.1 Measurement Tool Operations
Take measurement "Thyroid L" for example; the measurement procedures are as follows:
1. Select [Thyroid L] in the measurement menu.
2. Use the Distance of 2D General Measurements to measure Thyroid L. The value displays in
the result window and exam report.
10.4.2 Calculation Tool Operations
Thyroid Vol
Function: measures Thyroid L, Thyroid H and Thyroid W respectively, and calculates Thyroid Vol.
Tips: Need to be measured in left and right side respectively.
1. Select [Thyroid Vol] in the measurement menu.
2. Use the Distance of 2D General Measurements to measure Thyroid L, Thyroid H and Thyroid
W.
Two Thyroid Vols are calculated automatically.
10.4.3 Study Tool Operations
Thyroid
Function: measures Thyroid L, Thyroid H and Thyroid W respectively, and calculates Thyroid Vol.
See “10.3 Small Parts Measurement Tools” for calculation formulae.
Tips: Need to be measured in left and right side respectively.
1. Select the [Thyroid] in the measurement menu.
