Mindray DC-8 EXP User Manual

6-2 Cardiology
6.3 Cardiac Measurement Tools
The system supports the following cardiac measurements:
NOTE: 1. Measurement tools mentioned below are configured in the system. The application
measurement packages provided in this system are generally different
combinations of measurement tools. For more information about package preset,
see "2.4.2.2 Application Measurement Preset".
2. The heartbeat of the traced spectrum in VTI measurement should equal to that is
preset, otherwise the obtained HR (Heart Rate) is incorrect. See "2.2 Measurement
Parameters Preset" for relevant preset.
3. Some application items in the measurement preset library (and matching list in
result assignment) are displayed different from that in the measurement menu and
result window.
In preset library (and matching list in result assignment), the item is followed with
the word indicating the mode or location. Such as LA Diam (2D) means that the
item is measured during 2D mode; LA Diam(LA Vol A-L) means that the item is
contained in a study named LV Vol(A-L).
6.3.1 2D Cardiac Measurements
Types Tools Descriptions Methods or formulae
Measurement
LA Diam Left Atrium Diameter
Distance in 2D General
Measurements
LA Major Left Atrium major Diameter
LA Minor Left Atrium minor Diameter
RA Major Right Atrium major Diameter
RA Minor Right Atrium minor Diameter
LV Major Left Ventricular major Diameter
LV Minor Left Ventricular minor Diameter
RV Major
Right Ventricular major
Diameter
Distance in 2D General
Measurements
RV Minor
Right Ventricular minor
Diameter
LA Area Left Atrium area
Area in 2D General
Measurements
RA Area Right Atrium area
LV Area(d)
Left Ventricular area at end-
diastole
LV Area(s)
Left Ventricular area at end-
systole
RV Area(d)
Right Ventricular area at end-
diastole
RV Area(s)
Right Ventricular area at end-
systole
