5-40 Image Optimization
 Save clip: in 3D viewing mode, press the user-defined Save key (Save Clip
(Retrospective) to hard drive) to save a CIN-format clip to the hard drive.
 Image review
Open an image file to enter the image review mode. In this mode, you can perform the
same operations as in VR viewing mode.
5.12.4 Smart 3D
The operator manually moves the probe to change its position/angle when performing the
scan. After scanning, the system carries out image rendering automatically, then displays a
frame of the 3D image.
Smart 3D is an option. All probes for the Ultrasound System support the Smart 3D except for
D6-2EA.
5.12.4.1 Basic Procedures for Smart 3D Imaging
NOTE:
In Smart 3D image scanning, if the probe orientation mark is oriented to the
operator’s finger, perform the scan from right to left in linear scan, or rotate the
probe from left to right in rocked scanning. Otherwise, the VR direction will be
wrong.
To perform Smart 3D imaging:
1. Select the appropriate probe (non-4D probe) and exam mode. Make sure there is
sufficient gel on the probe for scanning.
2. Obtain a 2D image. Optimize the image as described in the Static imaging procedure.
3. Press <3D/4D> to enter the Smart 3D imaging preparation status, and define the ROI as
well as the curved VOI.
4. Select a render mode.
5. Select an acquisition method, and set the corresponding parameters on the screen.
Rocked mode: set [Angle] parameter.
Linear mode: set [Distance] parameter.
6. Press <Update> on the control panel to start the 3D image acquisition.
The system enters the 3D image viewing status when the acquisition is complete. Or, end
the acquisition by pressing <Freeze> or <Update> on the control panel.
In image viewing status, operations such as VOI setting and image editing can be performed.
7. Exit Smart 3D.
Press <Update> or <Freeze> to return to Smart 3D image acquisition preparation. Or,
press <B> or <3D/4D> to enter B mode.
5.12.4.2 Smart 3D Acquisition Preparation
In Smart 3D mode, you need to set the scan method in addition to the other items in Static 3D
mode. The other parameters are the same as those for Static 3D.
 Method
Capture images using Linear scan or Rocked scan.
 Linear scanning
Move the probe across the surface. See the following figure.
