Mindray Z50BW User Manual

Comments and Body Marks 8-5
2. Press <Set> key to select the body mark, and a frame will appear around the graphics.
3. Roll the trackball to move the Body Mark graphic to the desired position.
4. Press <Set> to anchor and confirm the new graphics position.
NOTE:
In Dual B Mode, a body mark cannot be moved between the separated image
windows.
8.2.5 Deleting Body Marks
 To delete a body mark
1. Use the trackball to position the cursor on the body mark graphic and Press <Set> to
select.
2. Press <Clear> to delete the selected body mark.
NOTE:
In the Body Mark mode, if no object is selected, pressing the [Clear] key will
clear all comments, body marks and general measurements from the screen.
Tips:
 Powering off, preset returning, switching the exam/ patient/ mode/ probe will clear the
body marks.
