Setup 11-11
Name
Description
IP Address
IP address of the PC installed with iStorage software, cannot be
empty
Connect
Press to verify connection with the PC server. On PC server, if the
storage path has not been confirmed, a dialog box will pop up and
guide the user to set it. If the storage path on PC has already been
set, here it displays connection successful after clicking this button.
Add
Click it to add the new service to the service list.
Update
To save the changed parameters.
Delete
Click to delete the selected service in the service list.
Default
Click to set an selected item in the list as the default iStorage server.
Save
Click to save and exit the screen.
 Add a network service:
1. Set the network server properties as described above.
2. Click [Add] to add the service to the Service list;
3. Select the added service in the service list, you can delete it.
 Modify a network service:
1. Select the service to be updated in the service list.
2. You can see properties in the Configure Service area.
3. Modify the parameters and click [Update] to update setting.
Tips: in order to make network storage function normally, setting of the sharing folder of the
PC server in advance is a must, e.g. machine name, IP address, should be confirmed at first.
You can send exam data of images to iStorage server by UltraAssist. For details about this
feature, please refer to the UltraAssist manual.
11.8 Maintenance
In the Setup menu, select [Maintenance] enter the screen.
11.8.1 Option
The system enters Option page after you enter the Maintenance screen. In Option list, the
system lists out all the system supported options and the installation status (Not installed or
Installed).
 Install and uninstall
 Click [Install] to begin the installation of a disabled option.
 Click [Uninstall] to begin the un-installation of an already installed option.
 Trial
Select the option item in the list to see the information on the Comment region on the
right. For functions that are not configured, you can use the function for free for 3 months.
 Click to select the function(s) and click [Trial].
Tips: Every trial option can be used only once. Please refer to the dependence
relationship between options in chapter “2.5.3 Options”.
Please contact Mindray Customer Service Department or sales representative for details.
