Mitsubishi 00JCPU User Manual

6 - 74
6.14 Sampling Trace Function
(1) Definition
This function samples the data of the specified device at a preset timing and at a preset interval (sampling cycle),
and then stores the trace results in the sampling trace file.Note17
(2) Application
This function is useful to check the change of the device data used in the program during debugging at a preset
timing.
In addition, this function is used to read the device data at trigger condition establishment.
(3) Sampling trace file
This file stores the trace setting necessary for executing the function and trace results.
● Sampling trace file can be stored only in the Standard RAM or SRAM card. ( Section 5.2.1(2))
● When storing a sampling trace file in the standard RAM, check the versions of the CPU module and GX Developer.
( Appendix 2)
Note17
Note6.15
Note6.15
The Basic model QCPU does not support the sampling trace function.
Basic
