Mitsubishi MELSEC Q Series Programming Manual

7-250
SIN(P)
Operation Error
(1) In any of the following cases, an operation error occurs, the error flag (SM0) turns ON, and
an error code is stored into SD0.
• The value of the specified device is 0.
*2
(For the Basic model QCPU, High Performance model QCPU, Process CPU, Redundant
CPU) (Error code: 4100)
*2: There are CPU modules that will not result in an operation error if 0 is specified. For details, refer to 3.2.4.
• The result exceeds the following range (Operation results in an overflow)
(For the Universal model QCPU, LCPU)
2
128
| Operation result | (Error code: 4141)
• The value of the specified device is 0, unnormalized number, nonnumeric, and ± .
(For the Universal model QCPU, LCPU) (Error code: 4140)
Program Example
(1) The following program conducts a SIN operation on the angles stored in the four BCD digits
from X20 to X2F and stores the results at D0 and D1 as 32-bit floating decimal point type
real numbers.
[Ladder Mode]
[List Mode]
[Operations involved when X20 to X2F designate a value of 150]
Inputs an angle used for SIN
operation ( ).
Converts the input angle into
a 32-bit floating-point real
number ( ).
Converts the converted angle
into a radian value ( ).
Executes SIN operati
on
using the converted radian value ( ).
1
2
3
4
Step Instruction Device
Conversion to radian
32-bit floating-point
real number
D21
D20
RAD
SIN operation
32-bit floating-point
real number
D11
D10
SIN
32-bit floating-point
real number
D1
D0
X2F
BCD value
0
D30
150
X20
Conversion to BIN
BIN
b15
b0
BIN value
Conversion to floating-point
FLT
150
150
2
.
617994 0
.
500000
