10-20
D(P).DDRD
Program Example
(1) This program stores data by 10 words starting from D0 in CPU No.2 into W10 or later in host
CPU when X0 turns on.
[Ladder mode]
[List mode]
Caution
(1) Digit specification of bit device is possible for n, , and . Note that when the digit
specification of bit device is made to or , the following conditions must be met.
• Digits are specified by 16 bits (4 digits).
• The start bit device is multiples of 16 (10
H).
(2) Execute this instruction after checking that the read target CPU is powered on. Not doing so
may end up no processing.
(3) If changing a range of the device specified at setting data between after execution of the
instruction and turn-on of the completion device, data to be stored by system (completion
status, completion device) cannot be stored normally.
S2
D1
S2
D1
