8 - 36 8 - 36
MELSEC-Q
8 UTILITY PACKAGE (GX Configurator-SC)
[Test Items]
The following accumulated count of times counter values can be cleared to "0" by
the select test function.
Test items
Setting value storage
buffer memory address
Reference section containing
detailed explanation
Accumulated count of unlock process normal completion 22FB
H
Accumulated count of unlock process abnormal completion 22FC
H
Accumulated count of lock process based on circuit disconnection 22FF
H
Callback permit accumulated count 22F0
H
Callback denial accumulated count 22F1
H
Auto (callback) connection permit accumulated count 22F2
H
Auto (callback) connection denial accumulated count 22F3
H
Accumulated count of callback receive procedure cancel 22F4
H
Section 3.3 of
User's Manual (Application)
[Operation procedure]
(Step 1) Display the "Modem function monitor/test" screen.
(Step 2) Click the setting value area of the item to be cleared to "0."
(Step 3) Click the " Execute test
."
The counter value of the selected item becomes "0."
