8 - 44 8 - 44
MELSEC-Q
8 UTILITY PACKAGE (GX Configurator-SC)
8.6.7 PLC CPU monitoring monitor
[Purpose]
Monitor the operating status and setting values of the PLC CPU monitoring
function.
[Startup procedure]
[Monitor] screen CH Monitoring monitor
[Monitor screen]
