Motorola APX4000 XH User Manual

A Softkeys
B Menu Select Buttons
C Data Feature Button
D 4–Way Navigation Button
E Home Button
Menu Select Buttons
Note
Check with your dealer or system
administrator for the list of features activated
in your radio.
Use the Menu Select button to access the menu
entry of your radio feature. Your radio may be
preprogrammed differently from the following
example, but the steps for selecting a channel may
appear as shown below:
Press the Menu Select button directly below Chan.
Home Button
Pressing the button returns you to the Home
(default) screen. In most cases, this is the current
mode. For selected radio features, the button is
also used to save user-edited radio settings or
information before returning you to the Home screen.
Note
Some features do not require you to press
to go to the Home screen. Refer to the
individual feature sections in this manual for
further details on saving user-edited radio
settings or information.
4-Way Navigation Button
Use the 4-Way Navigation Button to scroll up, down,
left or right with one of the following methods.
• Press and release one of the button to scroll from
one entry to the next one.
• Press and hold one of the button to have the radio
toggles through the list automatically (release the
button to stop).
Data Feature Button
Use Data Feature button to access data-related
features, such as the Text Messaging Service (TMS)
feature screen.
Identifying Radio Controls
32
English

Motorola APX4000 XH Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Yes
Bluetooth	Yes
Frequency Range	764-870 MHz
Dimensions	40 D mm
Encryption	AES, DES, ADP
