The radio shows different indicators based on the
system the radio is configured.
• For ASTRO Conventional system, the LED
lights up solid red. The display shows the
talkgroup alias or ID.
• For Trunking system, the LED lights up solid
red.
4 Speak clearly into the microphone.
5 Release the PTT button to listen.
Making a Private Call (Trunking Only)
Your radio must be preprogrammed to allow you to
use this feature.
This feature allows you to send an individual Call
Alert or page if there is no answer from the target
radio.
1 Perform one of the following actions:
• To access this feature via a preprogrammed
button, press the preprogrammed Quick
Access (One-Touch) Private Call button to
dial the preprogrammed ID (number) and
initiate the Private Call. Proceed to step 5.
• To access this feature via the menu, proceed
to the next step.
2
or to Call, and press the Menu Select button
directly below Call.
The display shows the last transmitted or received
ID.
3 To select the required ID, perform one of the
following actions:
• Press the Menu Select button directly below
Cnts to scroll through and select the required
ID.
• Press the Menu Select button directly below
LNum to go to the last number dialed.
•
or to the required ID.
• Use the keypad to enter the required ID.
4 Press the PTT button to initiate the Private Call.
The display shows Calling... <Number>.
5 Hold the radio vertically 1 to 2 inches (2.5 to 5.0
cm) from your mouth.
When you are connected, the display shows the
ID of the target radio.
General Radio Operation
59
English

Motorola APX4000 XH Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Yes
Bluetooth	Yes
Frequency Range	764-870 MHz
Dimensions	40 D mm
Encryption	AES, DES, ADP
