Motorola MTP850 User Manual

59
DMO Group Call
Upon selecting “Specific”, you will see one of the following
displays:
• The selected gateway address (e.g.:
1022), pre-programmed by your Service
Provider or previously entered by
yourself via the keypad. Press Edit and
then Ok to use the current address, or
press Edit and enter a new address via
the keypad, and press Ok. The
Gateway and Repeater icons will flash upon selecting
the gateway.
• “None”, indicating that no gateway was selected for that
talkgroup. Enter an address via the keypad, and press
Ok. The Gateway and Repeater icons will flash upon
selecting the gateway.
When the MTP850 detects the appropriate
gateway and/or the repeater, the Gateway
and/or Repeater icons will turn solid,
respectively.
Making a DMO Group Call (MS to MS)
1. Enter Direct Mode by pressing Optns and
selecting Direct Mode.
2. Make sure that you have selected the
required group. Press and hold the PTT
button.
3. Wait for the talk permit tone and then speak
into the microphone. Release the PTT button to listen.
Selected
Gateway
1022
DMO Folder 1
Police
Hello
Optns Contcs
Select Back
Config
MS - MS
Gateway
Repeater
GW + Rep

Motorola MTP850 Specifications

General

Network	TETRA
Operating Temperature	-20°C to +55°C
Display	QVGA (240 x 320) color display
Expandable Memory	MicroSD card slot
Connectivity	USB, Bluetooth
GPS	Integrated GPS receiver
Water and Dust Resistance	IP54
