ANTENNA ORIENTATION 10-3
Installation NWD-107460-02E
Notes
1. The RX LEV MON terminal on the ODU (conformed to IEC61169-24).
2. The RX LEV MON terminal must be capped for waterproof.
Caution: Be careful, surface of the ODU is hot in operation.
Fig. 10-1 Antenna Orientation Test Setup
Note The fixed bolts and nuts to be used for the antenna orientation differ with
antenna bracket types, refer to antenna bracket shown in Fig. 10-3 to
Fig. 10-7.
−
1
23
4
5
0
V
OW
FG
IFL
MON
RX LEV
ODU (6-11 GHz)
I
ODU (13-38 GHz)
A
View A
RX LEV MON
RX LEV/OW IN
DIGITAL MULTIMETER
RX LEV MON
R
PASOLINK MONITOR
Submission Prohibited
NEC Internal Use Only
