NEC SL100 User Manual

Item
No.
Item Input Data Default Description
Related
Program
Note
18 IP Duplication
Allowed Group
0 = Not Used
1=Group1
2=Group2
3=Group3
4=Group4
5=Group5
6=Group6
7=Group7
8=Group8
9=Group9
10 = Group 10
0 If there is an adapter
that has one IP ad-
dress coming into it
but has multiple ex-
tensions off of it.
Assign all the exten-
sions to a group so
that way the CPU
knows that the one
IP address is as-
signed to multiple
extensions.
15-05-01
20 Bottom Option
Information
0=NoOption
1 = ADA
2 = BHA
3 = WHA
0 Shows the type of
adapter installed.
10-03-10
26 DR700 Terminal
Type
0 = Not Set
2 = ITL-()D-1D/ITL-12BT-
1D/ITL-12PA-1D (without
8LKI (LCD)-L)
5 = Softphone
6 = CTI
9 = IP4WW-24TIXH
0 (V1.5
Changed)
27 Personal ID
Index
0 ~ 128 0 Used when the SIP
Multiline telephone
is using manual/auto
registration. Assign
each phone a
unique personal
index. Then go to
command 84-22 to
assign the user
name and password.
84-22
28 Addition Infor-
mation Setup
Select whether
to inform of ad-
ditional informa-
tion or not.
0 = Do not inform
1 = Inform
0 15-01-01
15-02-13
15-02-15
15-02-34
29 Terminal WAN-
side IP Address
0.0.0.0 ~
255.255.255.255
0.0.0.0
30 DTMF Play dur-
ing Conversa-
tion at Receive
Extension
0 = Do Not Play
1=Play
0
31 Alarm Tone
during Conver-
sation (RTP
packet loss
alarm)
0=Off
1=On
1
33 LAN Side IP
Address of Ter-
minal
0.0.0.0 ~
255.255.255.255
0.0.0.0.
35 Encryption
Mode On/Off
0=Off
1=On
0
36 DR700 Firm-
ware Version
00.00.00.00 ~ ff.ff.ff.ff 00.00.00.00 Indicate a current
firmware Version.
38 Paging Proto-
col Mode
0 = Multicast
1 = Unicast
2 = Auto
0 Sets the protocol
mode for the Paging
function.
39 CTI Override
Mode
0=Disable
1 = Enable
0
ISSUE 1.1SL1000
Program
15
Program 15 : Extension, Basic Setup2-126
