NEC SL100 User Manual

Item
No.
Item Input Data Default Description
05 NIC Interface 0 = Auto Detect
1 = 100Mbps, Full Duplex
2 = 100Mbps, Half Duplex
3 = 10Mbps, Full Duplex
4 = 10Mbps, Half Duplex
0 NIC Auto Ne-
gotiate
(CPU)
06 Network Ad-
dress Port
Translation
(NAPT) Router
Setup
0 = No (Disable)
1 = Yes (Enable)
0 If using an ex-
ternal NAPT
Router or not.
07 NAPT Router IP
Address(De-
fault Gateway
[WAN])
0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.255.255.254
192.0.0.1 ~ 223.255.255.254
0.0.0.0 Set the IP ad-
dress on the
WAN side of
router.
08 ICMP Redirect 0= NO, Signaling packets will follow the ICMP redirect mes-
sage.
1= YES, Signaling packets will NOT follow the ICMP redirect
message.
0 When receiv-
ing ICMP redi-
rect message,
this determines
if the IP Rout-
ing Table up-
dates
automatically
or not.
09 IP Address 0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.255.255.254
192.0.0.1 ~ 223.255.255.254
172.16.0.10 Set for
VoIPDB.
10 Subnet Mask 128.0.0.0
240.0.0.0
254.0.0.0
255.192.0.0
255.248.0.0
255.255.0.0
255.255.224.0
255.255.252.0
255.255.255.128
255.255.255.240
255.255.255.254
192.0.0.0
248.0.0.0
255.0.0.0
255.224.0.0
255.252.0.0
255.255.128.0
255.255.240.0
255.255.254.0
255.255.255.192
255.255.255.248
255.255.255.255
224.0.0.0
252.0.0.0
255.128.0.0
255.240.0.0
255.254.0.0
255.255.192.0
255.255.248.0
255.255.255.0
255.255.255.224
255.255.255.252
255.255.0.0 Set for
VoIPDB.
11 NIC Setup 0 = Auto Detect
1 = 100 Mbps, Full Duplex
3 = 10 Mbps, Full Duplex
5 = 1 Gbps, Full Duplex
0 Set for
VoIPDB.
Conditions
• The system must be reset for these changes to take affect.
Feature Cross Reference
None
ISSUE 1.1 SL1000
Program
10
Programming Manual 2-17
