10: INPUTS AND OUTPUTS
Refer to the illustration below for identication of inputs and outputs featured on the Mercury 310 controller,
and on the next page for an example of accessories available. For a description of functions and wiring, refer
to the following pages.
Mercury 310 Inputs and Outputs
N.O.
+V
+V
+V
+V
N.O.
N.O.
N.O.
N.O.
N.O.
N.C.
COM
COM
COM
COM
N.O.
COM
N.O.
COM
10K
Safety
Sensors
Loop Detectors
BlueBUS
+12 VDC
+12 VDC
(OFF in Standby)
+12 VDC
Guard
Station
Controls
(Step Mode)
Remote
Input
Fire Dept.
(Emergency
Access)
Control
N.O.
Control
Control
LOOP 1
(Obstruct)
LOOP 2
(Shadow)
LOOP 3
(Exit)
18-24V DC/
12V Solar
12V
Battery
Actuator Motor Connections
+
+
_
_
+12 VDC
(OFF in Standby)
COM
Step Button
Open Button
Latch Button
Fail-Safe Button
(On/Off)
Battery Health LED
Alarm
Battery Fuse
(30A)
DC/Solar Fuse (15A)
Battery Power
Indicator LED
DC/Solar Power
Indicator LED
OXI Radio Port
Radio Program:
Display
Arrow Buttons
Left & Right
Function
Knob
Firmware
Update
(Motor 1/Motor 2)
(Open, Close, Stop/Clear)
Gate Control Buttons
Open/Close Limit LEDs
Mercury 310 Power Outputs
Location Voltage Amps Standby Mode
INPUTS
12VDC 500 mA
On
SENSORS
LOOPS
On
OUTPUTS
R
U
N
L
E
A
F
D
E
L
A
Y
C
L
O
S
E
T
I
M
E
R
L
R
N
M
O
T
O
R
1
F
O
R
C
E
L
R
N
M
O
T
O
R
2
Mercury 310 Power Requirements
> Battery = 12VDC sealed lead acid
> Solar panel = 12V (17-20V MPP)
> DC input = 18-24V high current
Mercury 310
www.ApolloGateOpeners.com | (800) 878-7829 | Sales@ApolloGateOpeners.com
To Next Page
