12VDC power outputs are provided at four locations, as shown below for powering additional accessories
and sensors. Two of the power outputs switch o󰀨 when the controller enters Standby Mode and the other two
outputs remain powered during Standby Mode, as shown below.
SENSORS: OFF in Standby Mode
OUTPUTS: OFF in
Standby Mode
INPUTS: ON in Standby Mode
LOOPS: ON in Standby Mode
Mercury 310 Power Outputs
Location Voltage Amps Standby Mode
INPUTS
12VDC 500 mA
On
SENSORS
O󰀨
LOOPS
On
OUTPUTS
O󰀨
Mercury 310
