Oki Data CONFIDENTIAL
42930511TH Rev. 2
117 /
3
4
3
3
3
1
2
3
4.3.11
Motor-Pulse-Belt and Sensor-Resist-Assy
(1)
Unscrew the 2 screws
1
, then remove the 4-pin connector and remove the Motor-Pulse-
Belt
2
.
(2)
Unscrew 7 screws
3
, then remove the 3 connectors (2-pin, 14-pin, 3-pin), and remove
the Sensor-Resist-Assy
4
.
116
118
