Oki Data CONFIDENTIAL
42930511TH Rev. 2
246 /
8.
CONNECTION DIAGRAM
8.1
Check Resistance Value
Between Pin 1 and Pin 2: 4.7
Ω
Between Pin 3 and Pin 4: 4.7
Ω
Both ends of IP2: 1
Ω
or less
Both ends of IP2: 1
Ω
or less
Conveyance
Belt Motor
Main Motor (Y)
Main Motor (M)
Yellow
Orange
Black
Brown
M
1
2
3
4
Unit
Circuit Diagram and Configuration
Parts Diagram
Resistance Value
IC1
IP2
IC1
IP2
245
247
