Oki Data CONFIDENTIAL
42930511TH Rev. 2 167 /
6.4 Pickup Roller Cleaning
Clean the pickup roller if there is any problem with paper feeding.
Use a soft cloth, etc. with alcohol to clean the roller surface, with care not to scratch or
damage the surface during the process.
Note
Cleaning LED Head
Do the cleaning in case of light print, white line, or blurred print.
(1) Grasp the Top Cover Handle and open the Top Cover.
(2) Gently wipe the lens surface of the LED Head (4 places) using the LED lens cleaner or soft
tissue.
Note!
Do not use solvents such as methyl alcohol or thinner as they will damage the lens
surface.
Memo
An LED lens cleaner is enclosed in an optional replacement toner cartridge.
Do not touch it.The Fuser Unit is very hot. Do not touch it.
Personal injuries may occur.
(3) Close the Top Cover.
Lens surface of LED Head
Head Cover
2
1
Top Cover Handle
Top Cover
To Next Page
