Controlling Operation and Outputting Data with a Parallel Interface Sensor Data Unit
FQ2-S/CH User’s Manual
for Communications Settings
61
2
Controlling Operation and Outputting Data with a Par-
allel Connection
Performing Continuous Measurements
Continuous measurements are performed while the continuous measurement command is input from an
external device.
Setting Output Data
You can set the data to output after measurements.
Output Data
You can output any of the following data through the Parallel Interface Sensor Data Unit.
Outputting the Overall Judgement Result (OR Signal)
When the results of the inspection items are judged, if even one individual judgement result is NG, the OR
output signal is turned ON.
Data Output contents Signal used to output the data
Overall judgement
result
Judgement result of multiple inspection items
(ON if even one judgement result is NG)
The results is output with the OR signal.
Parallel judgement
output
Judgement results of the judgement conditions
that are set for parallel output
The results are assigned to and output with
D0 to D15.
Parallel data output Measurement values for inspection items and
results from expressions
The data is output as 16-bit data on D0 to
D15.
• You can also turn ON the overall judgement result output signal when all individual judgement results are OK.
Changing the Judgement Output ON Conditions: p. 44
• You can select whether to use the judgement result of one of the calculations (0 through 31) as the overall judge-
ment.
Section 4 Setting Up Inspections
in Vision Sensor FQ2-S/CH Series User's Manual (Cat. No. Z337)
• You can adjust the timing for outputting the OR signal and the ON time after judgement processing.
Adjusting the Judgement Output Timing: p. 42
PLC
(2) Performs continuous
measurements
Or other
device
(1) IN7 signal ON (IN0 to IN6 are OFF)
FQ2-S_CH_comm.book 61 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
