5-2
OPERATION
CHAPTER 5 OPERATION
5-1 Levels
The setting items of the product are grouped into five "levels" as follows.
During operation of the product, the level indicator designates the current level.
Alphabetic characters shown on the level indicator and their corresponding levels are
shown below.
Level Function
Measurement
Protect
This level allows parameter setting for protec-
tion against unauthorized or inadvertent key
operation. Access to protected levels or set-
ting items is disabled.
Yes
Operation
This level represents the normal operation
state in which the product can accept input
signals and provide comparative outputs. At
this operation level, not only readout of the
current process value but also access to or
changes of OUT set values are allowed.
The product enters this level at power-on.
Yes
Adjustment
This level executes specifying the tempera-
ture input correction value.
(Only K3MA-L.)
Yes
Initial setting
This level allows initial setting of the input
type, type of OUT set values, and scaling fac-
tor.
No
Advanced-func-
tion setting
This level allows setting of the number of
measurements for averaging. Customizations
such as a change in display color are also pos-
sible at this level.
No
Character
Level
p Protect level (Protect)
OFF Operation level
a Adjustment level (Adjustment)
s Initial Setting level (initial Setting)
f Advanced Function setting level (
advanced Function setting)
To Next Page
