168
Section 7 Modbus Communications Protocol
RFID System
User's Manual
(Modbus TCP)
Section 7
Host Communications Specifications
 Error Codes
If an exception code other than 00 hex (normal operation) is returned in the response from the Reader/
Writer, you can use a GET COMMUNICATIONS ERROR LOG query to get details on the nature of the
error.
The following tables list the error codes that indicate the response results from the Reader/Writer. If an
error response is returned (i.e., an error code other than 0000 hex), a record is recorded in the
communications error log in the Reader/Writer. Records are not recorded for errors for which
responses are not returned to the host device. Reader/Writer operating errors and system errors are
recorded in the system error log in the Reader/Writer.
 Normal Code
 Interrupted Processing
 Query Errors
 RF Tag Communications Errors
Error code name Error code Description
Normal end 0000 hex Processing ended normally.
Error code name Error code Description
Communications canceled 0001 hex Processing was canceled when a STOP query was received before an
RF Tag was detected.
(The contents of the RF Tag was not changed, even for a WRITE DATA
query.)
Communications aborted 0002 hex Processing was aborted when a STOP query was received during
communications with an RF Tag.
(For a WRITE DATA query, the contents of the RF Tag may have been
changed.)
Error code name Error code Description
Frame length error 1001 hex A frame with a length that exceeded the protocol specification was
received.
Frame header error 1002 hex The frame header did not agree with the protocol specifications.
Illegal query error 1003 hex A query that is not supported by the Reader/Writer was received.
Query format error 1004 hex There was an error in the format of the received query data.
Query parameter error 1005 hex There was an error in the parameters in the received query data.
Execution status error 1006 hex The Reader/Writer could not execute the query that was received.
Query response error
*1
1010 hex A response could not be returned for a query that was received by the
Reader/Writer.(An example would be a TCP/IP socket communications
send failure.)
*1. If a query response error occurs, the response from the Reader/Writer may not be received by the host device.Reconnect
to the Reader/Writer and check the cause of the error with a GET COMMUNICATIONS ERROR LOG query.
Error code name Error code Description
RF Tag missing error 2001 hex There is no RF Tag in the communications field.
RF Tag communications error 2002 hex Communications with the RF Tag did not end normally.
Tag ID mismatch error 2003 hex An RF Tag with the specified ID was not in the communications field.
RF Tag address error 2004 hex The access address for the RF Tag is outside of the area supported by
the target RF Tag.
RF Tag lock error 2005 hex An attempt was made to write data to a locked area.
RF Tag verification error 2006 hex Processing to write data to the RF Tag did not end normally.
