Section 7 Message Details
RFID System
User's Manual
(Modbus TCP)
Section 7
Host Communications Specifications
Controlling Reader/Writer Operation
 STOP
This query stops Reader/Writer operation.
 Query Format
 Response Format
Normal Response
Error Response
 Execution Example
Stopping Communications with RF Tags
TX: 00000000009FF10D1000001020000
RX: 00000000006FF10D1000001
Parameter Description
Register address The register address (D100 hex) that specifies the stop setting
Word count The number of words for the option (0001 hex)
Byte count The number of bytes for the option (02 hex)
Option Always 0000 hex.
Parameter Description
Register address Contains the register address that was specified in the query.
Word count Contains the word count that was specified in the query.
Parameter Description
Exception code For details, refer to Exception Code Table in this section.
p.167
Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8 Byte 9 Byte 10 Byte 11 Byte 12 Byte 13 Byte 14
Transaction
identifier
Protocol
identifier
Field length
Unit
identifier
Function code
Register
address
Word count
Byte
count
Option
XX 0000 hex 0009 hex FF hex 10 hex D100 hex 0001 hex 02 hex 0000 hex
Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8 Byte 9 Byte 10 Byte 11
Transaction
identifier
Protocol
identifier
Field length
Unit
identifier
Function code Register address Word count
X X 0000 hex 0006 hex FF hex 10 hex D100 hex 0001 hex
Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Transaction
identifier
Protocol identifier Field length
Unit
identifier
Function
code
Exception
code
X X 0000 hex 0003 hex FF hex 83 hex 1 bytes
