Omron V680 Series User Manual

RF Tag Installation Precautions
Section 11
Section 11
Appendices
307
RFID System
User's Manual
(Modbus TCP)
V680S-D8KF67M
 Influence of Surrounding Metal
The V680S-D8KF67M can be surface-mounted or it can be embedded in metal. However, do not allow
the height of the metal to exceed the height of the V680S-D8KF67M.
5 mm max.
Metallic material
Embedded
Metallic material
Surface-mounted
RF TagRF Tag
Distance (x) from surrounding metal
V680S-HMD64-ETN and V680S-D8KF67M
Communications range (range with metal at back surface = 100%)
V680S-HMD66-ETN and V680S-D8KF67M
xx
0
10
20
30
40
50
60
70
80
90
100
10 20 30 40 50 (mm)
(%)
0
10
20
30
40
50
60
70
80
90
100
10 20 30 40 50 (mm)
(%)
0
10
20
30
40
50
60
70
80
90
100
10 20 30 40 50 (mm)
(%)
V680S-HMD63-ETN and V680S-D8KF67M
Distance (x) from surrounding metal
Communications range (range with metal at back surface = 100%)
Distance (x) from surrounding metal
Communications range (range with metal at back surface = 100%)
Metallic material
RF Tag
