Section 5 Starting the Reader/Writer
RFID System
User's Manual
(Modbus TCP)
Section 5
Preparations for Communications
Starting the Reader/Writer
Reader/Writer Starting Procedure
1. Connect the Cable to the Reader/Writer.
Refer to Connecting and Removing the Reader/Writer Cable in Section 4 Installation and Connections for the connector method.
p.87
2. Connect the power supply lines and the operation mode signal line in the Cable to the power source
and connect the RJ45 connector to an Ethernet port on the host device.
Refer to Connecting the V680S-A41 @ M/-A51 @ M Cable to the Host Device in Section 4 Installation and Connections for the
connector method.
p.90
3. Turn ON the power supply to start the Reader/Writer.
If the Reader/Writer starts normally, the RUN indicator will light green.
