Omron V680 Series User Manual

RFID System
User's Manual
(Modbus TCP)
Section 1 Product Specifications
Section 1
Product Overview
27
Product Specifications
Reader/Writer
 General Specifications
Item Model V680S-HMD63-ETN V680S-HMD64-ETN V680S-HMD66-ETN
Compliance standards ISO/IEC 18000-3 (15693)
Frequency 13.56 MHz
Dimensions 50 × 50 × 30 mm (W × H × D,
excluding protruding parts)
75 × 75 × 40 mm (W × H × D,
excluding protruding parts)
120 × 120 × 40 mm (W × H × D,
excluding protruding parts)
Power supply voltage 24 VDC (-15% to +10%)
Consumption current 0.2A max.
Ambient operating
temperature
-10 to 55°C (with no icing)
Ambient operating
humidity
25% to 85% (with no condensation)
Ambient storage
temperature
-25 to 70°C (with no icing)
Ambient storage
humidity
25% to 85% (with no condensation)
Insulation resistance 20 MΩ min. (at 500 VDC) between cable terminals and case
Dielectric strength 1,000 VAC, 50/60 Hz for 1 min between cable terminals and case
Vibration resistance No abnormality after application of 10 to 500 Hz, 1.5-mm double amplitude, acceleration: 100 m/s
2
,
10 sweeps in each of 3 axis directions (up/down, left/right, and forward/backward) for 11 minutes
each
Shock resistance No abnormality after application of 500 m/s
2
, 3 times each in 6 directions (Total: 18 times)
Degree of protection IP67 (IEC 60529:2001)
Oil resistance equivalent to IP67F (JIS C 0920:2003, Appendix 1)
See Note 1
Materials Case: PBT resin, Filled resin: Urethane resin
Mass Approx. 120 g Approx. 270 g Approx. 640 g
Installation method Two M4 screws
Use a screw of 12 mm or more
in length.
Four M4 screws
Use a screw of 12mm or more in length.
Host device
communications
interface
Ethernet 10BASE-T/100BASE-TX
Host device
communications
protocol
Modbus TCP
Accessories Instruction Sheet
Description of Regulations and
Standard
IP address label
Instruction Sheet
Description of Regulations and
Standard
IP address label
Instruction Sheet
Description of Regulations and
Standard
IP address label
Ferrite core
Note 1. Oil resistance has been tested using a specific oil as defined in the OMRON test method.
