216
Section 7 Initializing All Settings
RFID System
User's Manual
(Modbus TCP)
Section 7
Host Communications Specifications
Initializing All Settings
Category Register address Query name R/W
RF Tag access 0000 to 9FFF hex DATA READ R
0000 to 9FFF hex WRITE DATA W
A000 hex READ ID R
A100 hex DATA FILL W
A200 hex LOCK W
A300 hex RF TAG OVERWRITE COUNT CONTROL W
A400 to A700 hex (Reserved) ---
A800 hex DATA COPY W
Reader/Writer settings B000 hex GET TAG COMMUNICATIONS OPTION R
B000 hex SET TAG COMMUNICATIONS OPTION W
B100 hex GET TAG COMMUNICATIONS CONDITIONS R
B100 hex SET TAG COMMUNICATIONS CONDITIONS W
B200 hex (Reserved) ---
B300 hex GET COMMUNICATION DIAGNOSTIC SETTING R
B300 hex SET COMMUNICATION DIAGNOSTIC W
B400 hex GET MULTI-READER/WRITER SETTINGS R
B400 hex SET MULTI-READER/WRITER SETTINGS W
B500 to B700 hex (Reserved) ---
B800 hex GET TCP/IP COMMUNICATIONS CONDITIONS R
B800 hex SET TCP/IP COMMUNICATIONS CONDITIONS W
B900 hex GET DEVICE NAME R
B900 hex SET DEVICE NAME W
BA00 hex GET TCP/IP COMMUNICATIONS CONDITIONS R
BA00 hex SET TCP/IP COMMUNICATIONS CONDITIONS W
BB00 hex GET WEB PASSWORD R
BB00 hex SET WEB PASSWORD W
BC00 hex GET MULTI-READER/WRITER STATUS W
BD00 to BE00 hex (Reserved) ---
BF00 hex INITIALIZE SETTINGS W
Getting Reader/Writer
information
C000 hex GET FIRMWARE VERSION R
C100 hex GET DEVICE INFORMATION R
C200 hex GET MAC ADDRESS R
C300 hex GET Reader/Writer OPERATING STATUS R
C400 hex GET OPERATING TIME R
C500 hex GET SYSTEM ERROR LOG R
C600 hex GET COMMUNICATIONS ERROR LOG R
C700 hex GET RECENT ERROR QUERY INFORMATION R
C800 hex (Reserved) ---
CA00 hex GET COMMUNICATIONS DIAGNOSTIC INFORMATION R
Controlling Reader/Writer
operation
D000 hex RESET W
D100 hex STOP W
D200 hex MEASURE NOISE R
